| Model | HT300 | HT200 | HT100 |
| Length (mm) | 660 | 580 | 356 |
| Weight (kg) | 33 | 25 | 23 |
| Shank Size (mm) | 22*108 or 25*108 | 22*108 | 22*108 |
| Output Flow (L/min) | 26-34 | 26-34 | 26-34 |
| Impact Frequency (bpm) | 800-1200 | 800-1200 | 800-1200 |
| Output Energy (Nm) | 70 | 60 | 60 |
| Frequency (Hz) | 15 | 18 | 20 |
| Max Drill Diameter (mm) | 76.2 | 50.8 | 50.8 |
| Working Pressure (bar) | 105-140 | 105-140 | 105-140 |
| Water Pressure (bar) | 0.8 max | 0.8 max | 0.8 max |
| Oil Temperature (°C) | 20-60 | 20-60 | 20-60 |
| Water Temperature (°C) | 30 max | 30 max | 30 max |
| Water Flow (L/min) | 12 | 12 | 12 |
| Max Drill Depth (m) | 6 | 3 | 1.5 |
